Product Details:

Place of Origin: Shandong, China
Brand Name: GXLASER

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: $12,920.00/sets >=1 sets
Payment Terms: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow
Get Best Price Contact Now

Detail Information
Application: LASER CUTTING, Industrial Metal Cutting Applicable Material: Metal
Condition: New Laser Type: Fiber Laser
Cutting Area: 600mm*900mm Cutting Speed: 150m/min
Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP CNC Or Not: Yes
Cooling Mode: WATER COOLING Control Software: Cypcut
Laser Source Brand: MAX Laser Head Brand: Raytools
Servo Motor Brand: FUJI Guiderail Brand: HIWIN
Control System Brand: Cypcut Weight (KG): 1000 KG
Key Selling Points: High-accuracy Optical Lens Brand: Wavelength
Warranty: 2 Years Applicable Industries: Hotels, Building Material Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction Works , Energy & Mining, Food & Beverage Shops, Other
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 2 Years Core Components: Motor, Laserhead, Laser Source, Control System
Mode Of Operation: Pulsed Configuration: Gantry Type
Products Handled: Sheet Metal Feature: Water-cooled
Product Name: Closed Fiber Laser Metal Cutting Machine Keyword: Fiber Laser Cutting Machiens
Cutting Materials: Stainless Steel Carbon Steel Laser Head: Raytools
Function: Cutting Metal Materials Model: C6090
Working Area: 600mmX900mm After Warranty Service: Repair Service
Type: Fiber Lasr Cutting

Product Description

Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 0
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 1
model
GX-6060C

GX-6090C


working area
600*600mm

600*900mm


X/Y axis positioning accuracy
±0.03mm




X/Y axis repositioning accuracy
±0.02 mm




maximum movement speed
150 m/min




maximum acceleration
1.5G




Laser Power
2-30kw

2-30kw
2-30kw
2-30kw
Laser Source
MAX/RAYCUS/IPG(optional)
1.5G
1.5G
1.5G

laser cutting head
OSPRI/ PRECITEC/ RAYTOOLS (optional)




servo motor
Fuji/Delta/INOVANCE/Yaskawa (optional)




Control systems and software
CYPCUT/RAYTOOLS




Reducer
Shimpo




Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 2
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 3
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 4
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 5
Max laser source
It has the advantages of high electro-optical conversion efficiency, good beam quality, high energy density, wide modulation
frequency, strong reliability, long life, and maintenance-free operation. It can be widely used in welding, precision cutting,
cladding, surface treatment, 3D printing and other fields. Its optical fiber output characteristics make it easier to integrate
with robots into flexible manufacturing equipment to meet the needs of three-dimensional processing.


Removable display
Customers can adjust the direction of the display screen at will according to processing needs, which greatly facilitates customer
use and improves processing efficiency.
32 inch screen with high definition toughened glass,It is stable and reliable, easy to adjust, and has complete functions. The
system is comprehensively displayed on the screen, which makes the operation easier and improves the operation efficiency and
processing efficiency.
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 6
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 7
Raytools Auto focus laser head
The software automatically adjusts the focal length to complete rapid perforation and cutting of sheets of different
thicknesses.It is more friendly to those with zero experience, and the operation is simple, convenient, fast and accurate.
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 8
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 9

Aviation Aluminum Beam

The beam is made of aviation-grade extruded aluminum, which has the advantages of good toughness, light weight, corrosion
resistance, oxidation resistance, low density, etc. It also has excellent dynamic performance, which is conducive to high-speed
cutting.
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 10

Accuracy measurement

Original 35mm Taiwan YYC rack, Hiwin guide rail.Greater carrying capacity to the thickness of the metal to be cut.and with Automatic lubrication system it can help the users more convenient and save more time .

Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 11

Detailed control

Whole machine delivery, no installation is required, and it is ready to use when plugged in.
Industrial computer, good cooling
effect, dustproof.
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 12

Testing made before shipment.

each customers machine all be tested and runing more than 24h in our factory and testing kind of materails and thickness and save the parameters for all of the customers .
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 13

High quality accessories guaranteed

with top brand Raycus Auto focus laser head. it is more convenient for without any using experience customers to make adjustments .and long using life
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 14

Quality control

Ensure the accuracy of cutting parameters and ensure high-quality cutting samples.it will be more stable for customer working
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 15
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 16
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 17
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 18
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 19
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 20
Raytools Laser Head Metal Stainless Steel Tube and Iron Sheet Automatic Closed Fiber Laser Cutting Machine 21
Q: What is a fiber laser cutting machine? A: Fiber laser is a special type of solid laser. Typically, fiber lasers are optically pumped, which is accomplished by coupling the radiation from a diode maser or other fiber laser into the cladding or core itself in a direction parallel to the fiber core. In many cases, to achieve higher output power, double-clad fiber is used. What materials can fiber laser cut? Various metals such as stainless steel, carbon steel, mild steel, galvanized steel, aluminum,Copper etc. Q: Do you have CE documents and other customs declaration documents? A: Yes, we have the original. First, we will show you and give you CE/packing list/commercial Invoice/sales contract for customs clearance. Q: Payment terms? A: Alibaba Trade Assurance/TT/Western Union/Payple/LC/Cash, etc. Q: I don’t know how to use it after receiving it, or I encounter problems during use. What should I do? A: We can provide cam for team viewer/Whatsapp/email/phone/Skype until you solve all the problems. Q: What is your MOQ? A: We have no MOQ. Whether it is an order for 1 set or 100 sets, we will support you wholeheartedly. Q: How does your factory do in terms of quality control? A: Quality is priority. Each OREE laser machine will undergo 24 tests. After all 24 items are passed, our QC will conduct a 48 to 72 hours reliability test. Our laser machine has obtained CE.
